Nokia 5235 Mic Problem Repair Solution With Jumper Ways Succseefully Mobile Phono 2016

Nokia 5235 Mic Ways Jumper Problem Repair Solution

Here’s the solution that might possibly help fix a Nokia 5235 with a not working mouthpiece microphone problem. This solution may serve as a guide to troubleshoot the mic circuit on Nokia 5235.

The Nokia 5235 digital microphone module is being mounted or connected to the keypad UI ( user interface) flex assembly. You may need to check the UI flex first for possible damaged and replace it, if found out. The solution below shows the connection line paths of the microphone on Nokia 5235. You may need to check this connection line paths too; Before replacing the microphone module.

Hardware Solution:

Nokia 5235 Microphone ( MIC – Mouthpiece ) Problem solution – MIC ways
Nokia 5235 Mic Problem Solution mic jumper ways tracks
The highlighted components and tracing spots on the solution above is useful for a wet damaged nokia 306 for this line paths may possibly cut-off and result to microphone problem on nokia 306

Damage or repair errors caused by existing solutions in this blog are not the responsibility MobileRdx.com, we just want a little help you in improving mobile phone.
